KEY FEATURES

• Hydraulic dump and drive
• Reversible mixing paddles to prevent clogging
• Vertical paddle orientation to cut through material for a homogeneous mix
• Loads below waist level and dumps high to lessen the backaches
• Fork pockets accessible from all sides
• Adjustable legs and outriggers for stability
• Patented rubber blades provide longer wear
• Variable speed control to accommodate separate mix designs
• Bolt-in abrasion resistant drum liners

RMH12 Specifications

• 500 lb. (227 kg) drum capacity
• Will mix up to ¾" (1.9 cm) aggregate
• Empty weight 2000 lbs. (909 kg)
• Hydraulic dump system
• Hydraulic drive system
• 15-gallon hydraulic reservoir
• Overall dimensions (L × W × H) 82" × 42" × 49"

Options

• Power Source
  • 10 HP Electric Motor - 1PH/230V (Standard)
  • 10 HP Electric Motor - 3PH/230V
  • 10 HP Electric Motor - 3PH/460V
  • 11.7 HP Honda Gas Engine
• Solid grating available to minimize dust
• Water bar with re-settable meter for easy filling
• Custom modifications available upon request
• Bolt-in abrasion resistant drum liners
• Axle kit for portability and towing light kit for road safety
