- The welded drum is manufactured using high abrasion-resistant steel, giving Crown mixers longer life with less maintenance.
- Two sets of laser cut steel blades provide a smooth, fast and more thorough mix.
- Crown’s new dumping mechanism comes standard with a multi-position drum lock for easy cleaning, flexibility and greater capacity.
- SAFETY CHAINS COME STANDARD ON ALL CROWN CONCRETE MIXERS
- Crown’s rugged tow pole is retractable or removable and easily stows away when not in use for safer operation.
- Our newly redesigned frame provides improved durability and stronger support in the areas you need it.
- Crown’s innovative optional rubber torsion suspension system provides the industry’s smoothest towing and handling.*
- High speed taper roller bearings are standard on all towable Crown mixers for improved durability.
- Sturdy vented engine housing comes standard with a swing-away hood, providing easy engine access.
- Our drive pinions and gear rings are made with cast iron, providing better durability and longer life.
Capacity Bag | 1 - 1 1/2 |
Cubic Feet | 9 |
Overall Height - (Drum Up/Down) | 70"/63.5" |
Overall Width | 51.5" |
Tires (Pneumatic) | B78 x 13 |
Overall Length (Tow pole In/Out) | 78"/98" |
Weight - Max lbs | 860 |
Highway Towable | Yes |
Drum Opening Diameter | 19" |
Drum Diameter - Max | 32" |
Drum Height | 31" |
